Colour Mixer

General Details
We are engaged in offering Tile Mixers that are used to produce tiles by pouring slump concrete in to rubber molds. These tile mixers are also provided with wear lining so as to ensure an effective and durable application. Our valuable clients can also avail from us The customization of these mixers as per their specifications.



enqiry
Specification
Capacity Recommended for color mix
100 kg /batch
Recommended for base mix
200 kg/batch
Power 2 H.P motor 3 H.P motor
Drum Speed 700mm dia x 300 mm height
Detachable from the machine after tilting up the mixer arms
1000 mm dia x 300mm height
Detachable from the machine after tilting up the mixing arms
Dimension l x b x h 1210 x 910 x 1050 1350 x 910 x 1050mm
Total weight 310 kg 400 kg
